Bondtech Stainless Steel Heat-break for Prusa Mini

Bondtech

/

Shop

/

Upgrade Kits

/

Prusa

/

Mini

/

Bondtech Heat-break Kit for Prusa Mini

SKU: 15067 Categories: , , Tags: , , , , , Brand:

Bondtech Heat-break Kit for Prusa Mini

To solve the heat-creep

This Stainless Steel heat-break made by Bondtech for the Prusa Mini addresses and solves the heat-creep issues revealed during the extensive testing we performed on the Prusa Mini.

The adjusted length of the PTFE tube also prevents clogs to form between tube and heat-break.

Now shipping with Silver based thermal grease.

Price:

$14.90

In stock (can be backordered)

Select Currency

Select Country

EAN Code:

7350011411061

Included in this kit:

  • 1x 32×5.48 mm stainless steel heat-break
  • 1x 35.3 mm 2/4 chamfered PTFE tube
  • 1x Silver based thermal paste bag [14118]

Recommendation

We recommend to use the included silver based thermal grease to properly fit the Bondtech heat-break in the Mini’s heat-sink.

Notes on twisting the heat-break

To address the heat creep issue the design features a narrower section with thinner walls. When removing the heater block or changing nozzles, caution is required.

Before removing the heater block from the heat-break (or vice versa), heat-up the nozzle, hold the heater block and release some tightening pressure from the nozzle. Let the whole group cool down. After, you can simply unscrew the heat-break from the heater block.

To remove or replace a nozzle, never forget to secure the heater block before twisting the nozzle.


Community Sourced Design

This heat-break design was proposed to us by Olof Ogland and we adjusted it to its final form during the deep testing we performed on the Prusa Mini.

Freight Weight 5.7 g
Dimensions 8 × 6 × 1 cm

Teaching Tech Video

A-Make video

Video Guides


AG Silver TDS and SDS

Check the TDS (Technical Data Sheet)
and SDS (Safety Data Sheet)
by clicking each of the corresponding links.
