Upgrade Kit for Prusa Mini
Bondtech high-resolution extruder upgrade for the Prusa Mini enabled with Dual Drive Technology.
Upgrade Your Prusa Mini
Upgrade your Prusa Mini with a Bondtech Dual Drive extruder designed to seamlessly fit the original setup.
Hardened Drive Gears
Allows to use abrasive materials that would wear out the gears of your original feeder otherwise.
Print Faster Or With Higher Quality
This bowden extruder will allow your 3D printer to print faster or to achieve even better surface quality.
€69.84
- Description
- Additional information
- STEP BY STEP GUIDES
- Teaching Tech Video
- A-Make Designs Video
- Reviews (1)
Adjustable tension
The thumbscrew tensioner allows the user to fine-tune the pressure exerted by the drive gears onto the filament. This gives you the power to adjust according to your preferences and to optimize for the type of material you are using.
Quick-Release
To be able to do material changes in a snap, simply activate the Quick-Release lever to release the tension and pull the material to be changed out of the extruder, keep it activated and insert the new material.
More choice of materials
The hardened steel Dual Drive gears allow you to work with common and abrasive materials.
Included in this Kit
- 1x Bondtech extruder for Prusa Mini
- 3x Black nylon zip-ties
- 4x M3x35 black oxide steel screws
- 1x M3x12 black oxide steel screw
- 1x Brass motor gear
- 1x Thumb Screw assembly
Community Sourced Design
This extruder design was proposed to us by Olof Ogland. It’s based on the thoroughly tested BMG (Bondtech Mini Geared) and adjusted to the Prusa Mini original design.
Product Info
EAN Code: 7350011411054
Net weight : 102.3g
Gearing ratio : 3:1
E-steps value : 415
Extruder Housing: SLS Printed parts in PA12;
Hinge: injection molded.
| Freight Weight | 165 g |
|---|---|
| Dimensions | 13.5 × 9.5 × 6.0 cm |
STEP BY STEP GUIDES
Find our Step By Step Guide to install the Prusa Mini Upgrade Kit here
Teaching Tech Video
A-Make Designs Video
1 review for Upgrade Kit for Prusa Mini
Only logged in customers who have purchased this product may leave a review.
Related products
€177.26
From: €102.06
€198.75
Robin Schumacher (verified owner) –
Good instructions and works flawless so far with the filaments the original extruder had problems.. I also have a i3 but atm the mini with the bondtech extruder is so much fun that i print everything that fits on the build plate with it. Only problem is that prusa has changed the eeprom with firmware 4.0.5 which does not allow amymore to store the esteps (M92) and filament unloading length (M603) permanently.
